raygui-jlt: raygui controls in Jolt

Why this is interesting

raygui's API is 61 functions that nearly all share one shape: a bounding Rectangle passed by value, application state through a pointer, an int result. Exactly one struct crosses that ABI by value anywhere in the control surface, which is rare enough to be worth explaining outright:

Rectangle → one scratch buffer

Every control takes its bounds as a 16-byte Rectangle by value. jolt's [:by-value ...] copies those bytes into caller-owned native memory at call time and never retains the pointer, so one module-level scratch Rectangle, rewritten immediately before each call, is safe for all 24 examples. No example allocates or frees a Rectangle inside a frame.
GuiScrollPanel → the one exception

The only raygui function taking two by-value Rectangles in a single call: its own bounds and the size of the content behind it. Clojure evaluates arguments left to right, so writing both through the same scratch buffer would let the second write clobber the first before the call ever happens. scroll-panel gets a second buffer for exactly this.
RAYGUI_APP_AUTO_QUIT_MS / RAYGUI_APP_SHOT → proof without a display

Every preview on this site is a real capture, not a mockup: RAYGUI_APP_AUTO_QUIT_MS closes the window on a timer and RAYGUI_APP_SHOT dumps a frame to PNG first, so a windowed example proves itself unattended. raygui is mouse-driven by definition and synthetic clicks don't actuate a real raylib/GLFW window, so this pair is the only way to verify a control headlessly, not just the convenient one.

How it fits together

flowchart LR
  subgraph ex["24 example namespaces"]
    e["basic-controls · sliders · tab-bar
style-selector · scroll-panel · …"]
  end
  subgraph shared["net.b12n.raygui-jlt.raygui: one shared layer"]
    kw["keyword-argument control API
button! · slider! · panel! · …"]
    fb["jolt.ffi/defcfn binds
positional, mirroring C"]
    kw --> fb
  end
  lib["lib/libraygui.dylib
built from the vendored header"]
  rl["system libraylib
already loaded by the jolt process"]
  e --> kw
  fb -->|"Rectangle by value, one scratch buffer"| lib
  lib -->|"GetMousePosition, DrawRectangle, …"| rl

Every example is a small namespace over that one shared layer. Adding one touches exactly five places: the source namespace, a deps.edn alias, a check.clj require, a registry row in scripts/examples_registry.clj, and a bb.edn task.

What's here

Header-only, so this repo builds its own library

raygui ships one header, not a compiled library: no brew install, no package to find. bb lib:build compiles the vendored raygui.h into lib/libraygui.dylib, linked dynamically against the same raylib the process loads.

One binding layer

All the FFI binds, the keyword-argument control API, and cell handling for all eight cell types live in a single namespace. Examples stay small enough to read in one sitting.

Reads like Clojure, not like C

(rg/button! :x 24 :y 24 :w 120 :h 30 :text "Save"): positional binds at the boundary, keyword wrappers on top.

Provable without a display

RAYGUI_APP_AUTO_QUIT_MS closes the window on a timer and RAYGUI_APP_SHOT dumps a frame to PNG, so a windowed example can prove itself unattended.

A compile gate over all 24

bb check requires every example namespace headlessly. No window, no JVM, and it catches a broken binding across the whole suite at once.

A screenshot gate, not just a compile gate

A control drawn at the wrong bounds, or a style that never loaded, compiles perfectly and passes bb check. Looking at the actual PNG is the gate that catches it.

Quickstart

bb lib:check       # is raylib installed, and is libraygui already built?
bb lib:build       # …compile the vendored header into lib/libraygui.dylib

bb info            # grouped cheat-sheet of every example
bb style-selector  # run one (opens a window)
bb check           # headless compile-check of all 24, no window

Needs jolt and a system libraylib (raygui links against it dynamically at build time). babashka is optional but gives every example a friendly task; without it each one is a jolt -M:<alias> away. raygui.h is vendored at 5.0-9-gfbf5d95, zlib licensed, the same license this repo ships under.

A few of them
